| Bill. | Pig Size | *Ø OD (mm) | THICKNESS (mm) | LENGTH (mm) | MAGNETS | EST. | |||||||
| CUP | SPACER | T1 | T2 | L1 (±10) | L2 (±10) | 0VERALL (±15) | SIZE | QTY | WEIGHT kg |
||||
| 1 | 4″ | 110 | 60 | 18 | 10 | 135 | 163 | 216 | S | 2 | 2 | ||
| 2 | 6″ | 162 | 92 | 25 | 15 | 182 | 224 | 295 | S | 4 | 5.3 | ||
| 3 | 8″ | 213 | 125 | 40 | 15 | 232 | 290 | 393 | S | 4 | 9.16 | ||
| 4 | 10″ | 267 | 162 | 47 | 20 | 304 | 358 | 487 | S | 4 | 14.5 | ||
| 5 | 12″ | 321 | 200 | 57 | 25 | 376 | 442 | 532 | S | 6 | 26.3 | ||
| 6 | 14″ | 352 | 220 | 58 | 25 | 409 | 500 | 591 | L | 10 | 43.7 | ||
| 7 | 16″ | 405 | 220 | 70 | 25 | 445 | 540 | 643 | L | 10 | 50.7 | ||
| 8 | 18″ | 450 | 310 | 75 | 25 | 515 | 610 | 720 | L | 16 | 78.5 | ||
| 9 | 20″ | 500 | 360 | 75 | 30 | 560 | 675 | 785 | L | 16 | 111 | ||
| 10 | 22″ | 560 | 360 | 75 | 30 | 590 | 705 | 815 | l | 16 | 117.5 | ||
| 11 | 24″ | 603 | 400 | 89 | 30 | 736 | 854 | 983 | L | 20 | 139.4 | ||
| 12 | 28″ | 711 | 520 | 98 | 40 | 772 | 927 | 1075 | L | 28 | 228.5 | ||
| 13 | 30″ | 762 | 625 | 105 | 40 | 800 | 960 | 1115 | L | 28 | 262 | ||
| 14 | 32″ | 813 | 660 | 105 | 40 | 895 | 1055 | 1210 | L | 32 | 292 | ||
| 15 | 36″ | 922 | 660 | 122 | 45 | 1013 | 1173 | 1345 | L | 40 | 354 | ||
| 16 | 40″ | 1020 | 725 | 125 | 45 | 1110 | 1290 | 1470 | L | 40 | 478 | ||
| 17 | 42″ | 1070 | 725 | 125 | 45 | 1222 | 1407 | 1589 | L | 40 | 521.5 | ||
| 18 | 48″ | 1240 | 880 | 135 | 60 | 1360 | 1595 | 1802 | XL | 72 | 663 | ||
| 19 | 52″ | 1340 | 1000 | 150 | 60 | 1580 | 1820 | 2042 | XL | 72 | 870.4 | ||
| 20 | 60″ | 1550 | 1200 | 160 | 60 | 1647 | 1887 | 2121 | XL | 72 | 1203 | ||
